JLG X20J – 20m Max Working Height Diesel Boom lift
Bi-Energy Compact Crawler Articulating Boom Lift
Key Specs
- Max Working Height: 20.05 m / 65.78 ft
- Platform Capacity: 230 kg / 507 lb
| Specifications | |
| Max Working Height | 20.05 m |
| Max Platform Height | 18.05 m |
| Max Outreach (horizontal) | 9.85 m |
| Platform Size | 0.69 x 1.34 m |
| Max Platform Capacity | 230 kg |
| Weight | 2,840 kg |
| Power Source | Diesel Engine Perkins 402D05 10.2 kW (14 hp) AC Electric Motor 230V, 50 Hz 2.2 kW |
| Stowed Length | 5.0 m |
| Stowed Width | 0.80 m |
| Stowed Height | 1.99 m |
| Ground Clearance | – |
- Specialist design: near square out rigger pattern, removable outrigger pads, removable basket and equipped with a crawler carriage allowing it to climb grades up to 28%
- Exceptional flexibility: equipped with an electrical engine as well as a diesel, optional lithium batteries are available. The plus series also offer 230kg unrestricted platform capacity so you can reach more (no work envelope restriction)
- Rentability: forklift housing pockets for easier transport, removable control box
