Genie S-85 XC – 27.9m Max Working Height Boom lift
Diesel Powered Telescopic Boom lift
Key Specs:
- Max Working Height: 27.91 m | 91.5 ft
- Platform Capacity: 300 kg ~ 454 kg | 660 lb ~ 1000 lb
| Specifications | |
| Max Working Height | 27.91 m |
| Max Platform Height | 25.91 m |
| Max Outreach (horizontal) | 22.71 m |
| Platform Size | 0.91 x 2.44 m |
| Max Platform Capacity | 454 kg |
| Weight | 18,126 kg |
| Power Source | Diesel Deutz TD 2011 L04i, 74 hp (55 kW) |
| Stowed Length | 12.37 m |
| Stowed Width | 2.49 m |
| Stowed Height | 2.8 m |
| Ground Clearance | 0.40 m |
Overview
• Full-time active oscillating axle and full-time positive traction for superior terrainability
• Chassis tilt sensor technology maximizes access to hard-to-reach work areas
• 1.52 m (5 ft) robust articulating jib
• Dual lifting capacity of 300 kg (660 lb) and 454 kg (1,000 lb) to lift increased loads and up to 3 operators
• Automatic envelope control technology for a smooth operating envelope
• Zero-load field calibration and onboard diagnostics maximize serviceability
