Snorkel SL26RT RT Electric Scissor Lift – 9.6m Max Working Height
Key Specs:
- Max Working Height: 9.6 m | 31 ft 6 in
- Platform Capacity: 680 kg | 1,500 lbs
Download Specs Sheet
| Specifications | |
| Max Working Height | 9.6 m |
| Max Platform Height | 7.8 m |
| Platform Length (Extended) | 4.57m |
| Platform Width | 1.73 m |
| Platform Capacity | 680 kg |
| Weight | 3,550 kg |
| Overall Length | 3.79 m |
| Overall Width | 2.13 m |
| Stowed Height (Rails Up) | 2.59 m |
| Stowed Height (Rails Down) | 1.65 m |
| Ground Clearance | 190 mm |
| Power Source | Diesel |
Standard Features
- Automatic powered platform leveling
- Powerful 4 wheel drive
- Oscillating front axle
- Roll-out deck extension
- Descent alarm
- High grip, all-terrain tires
- Dual multi-disc brakes
- Proportional controls
- Flashing amber light
- Power line to platform
- Fold-down guardrails
- All motion alarm
- Hour meter & on-board diagnostics display
- Horn
