Sinoboom AB10J – 12.3m Max Working Height Boom lift
Diesel Powered Articulating Boom Lift
Key Features:
- Max Working Height: 12.39 m | 40.6 ft
- Platform Capacity: 250 kg | 551 lb
| Specifications | |
| Max Working Height | 12.3 m |
| Max Platform Height | 10.3 m |
| Max Outreach (horizontal) | 5.75 m |
| Platform Size | 0.76 x 1.42 m |
| Max Platform Capacity | 250 kg |
| Weight | 4,986 kg |
| Power Source | Diesel Kubota D1105 18.2kW |
| Stowed Length | 5.28 m |
| Stowed Width | 1.85 m |
| Stowed Height | 1.83 m |
| Ground Clearance | 0.25 m |
Rough Terrain Performance
- The machine features excellent rough terrain performance thanks to its active oscillating function combined with wheel drive, gradeability, and high ground clearance, making it easily adaptable to both indoor and outdoor applications.
Large Platform Capacity
- Two persons with tools can be easily loaded on the platform to complete jobs efficiently, supported by its leading platform capacity of up to 550 kg.
Easy Transport
- It can be easily loaded onto trucks and transported in cities due to its light weight of less than 2 tons, and fewer limitations for some special projects.
Greater Tilt Rating
- The machine can be easily adapted to terrains that require a greater tilt rating and helps to boost work efficiency.
Ultimate HMJ Experience
- Easy trouble shooting with manuals free; a one-button for fault inquiry, and all faults will be displayed on the screen without codes, making it easily readable to minimize downtime.
- Easy calibration: tools are not needed for calibration as all settings are available on the screen.
