JLG 670SJ SL – 22.3m Max Working Height Boom lift
Diesel Powered Telescopic Boom Lift
Key Specs
- Max Working Height: 22.36 m / 73.4 ft
- Platform Capacity: 250 kg ~ 340 kg / 551 lb ~ 749 lb
| Specifications | |
| Max Working Height | 22.36 m |
| Max Platform Height | 20.36 m |
| Max Outreach (horizontal) | 17.4 m |
| Platform Size | 0.91 x 2.44 m |
| Max Platform Capacity | 340 kg |
| Weight | 11,494 kg |
| Power Source | Diesel Deutz T4F 67 hp / 50 kW |
| Stowed Length | 10.68 m |
| Stowed Width | 2.5 m |
| Stowed Height | 2.54 m |
| Ground Clearance | 0.33 m |
