Bluelift SA18HB – 17.8m Max Working Height Boom lift
Engine Powered Compact Crawler Boom Lift
Key Specs
- Max Working Height: 17.8 m / 58.7 ft
- Platform Capacity: 230 kg | 507 lb
| Specifications | |
| Max Working Height | 17.8m |
| Max Platform Height | 15.8m |
| Max Outreach (horizontal) | 9.3 m |
| Platform Size | 0.7 x 1.3 m |
| Max Platform Capacity | 230 kg |
| Weight | 2,300 kg |
| Power Source | Engine Honda iGX | Electric motor 230 V – 2,2 kW |
| Stowed Length | 4.44m |
| Stowed Width | 0.84 m |
| Stowed Height | 1.99 m |
| Ground Clearance | – |
- Quickly removable aluminum basket
- Basket rotation
- i-Performing electric pump (patented) with auto Start/Stop system
- 230V power outlet in basket
- Cable remote control with interactive and multi-lingual display
- Moment limiting device
- Automatic center position of turret
- Self Stabilizing system
- Automatic START & STOP of engines and RPM control
- Proportional and simultaneous electro-hydraulic controls
- Proportional track drive with hydraulic breaking system
- Double drive speed system with safety control
- Driving lateral slope alarm with safety stop
- Driving possible with jib boom raised (with selector)
- Interblock outriggers/booms
- Emergency push-button with engine stop
- Simple emergency lowering procedure
- Hand pump for the emergency lowering of platform
- Covers on outrigger cylinder’s piston rod, oil tank and emergency controls
- Modem connection plug for diagnosis/software upgrading in remote
- Produced according to EN280 norm and international safety regulation
