JLG 1230ES Vertical Lift
The 1230ES mast lift is compact enough to fit in a freight elevator and lightweight enough to be used on weight-sensitive floors. A platform height of 12 ft allows you to work comfortably at 16 ft. A super-efficient electric drive increases uptime—plus, it’s extremely low maintenance.
Whether you’ve got work to do in factories, retail centres, airports or public buildings, JLG® Mobile Vertical Lifts keep you on the job longer. A pair of reliable direct electric drive motors deliver power while maintenance-free long cycle batteries hold their charge. The built-in, automatic charger has a five-hour recharge capability.
Key Specs
- Platform Height: 3.66 m / 12 ft
- Machine Width: 0.76 m / 2.5 ft
Key Features
- Low maintenance, energy efficient and environmentally clean
- Longer running time than any lift in its class keeps you on the job longer, increasing your productivity
- Lightweight design for transport in freight elevators
| Dimensional Data | |
| Wheel Size – Front Caster | N/A |
| Ground Clearance | 0.07 m / 3 in. |
| Ground Entry Height | 0.56 m / 1 ft 10 in. |
| Machine Height | 1.65 m / 5.4 ft |
| Machine Length | 1.36 m / 4.5 ft |
| Machine Width | 0.76 m / 2.5 ft |
| Platform Dimension A | 0.69 m / 2.3 ft |
| Platform Dimension B | 1.26 m / 4.1 ft |
| Platform Height | 3.66 m / 12 ft |
| Wheel Size – Rear | N/A |
| Tyre Size | 100 x 323 (Solid, non-marking) |
| Reach Specifications | |
| Platform Height | 3.66 m / 12 ft |
| Working Height | 5.66 m / 18.6 ft |
| Performance Data | |
| Drive Speed – Platform Elevated | 0.80 km/h / 0.5 mph |
| Drive Speed – Platform Lowered | 4.80 km/h / 3 mph |
| Drive System | 24V Electric |
| Gradeability | 25 % |
| Maximum Drive Height | 3.66 m / 12 ft |
| Maximum Lift Height | 3.66 m / 12 ft |
| Platform Capacity | 230 kg / 507.1 lb |
| General Specifications | |
| Machine Weight | 806 kg / 1776.9 lb |
| Power Source | |
| Batteries | 4 x 6V, 220 A-h |
- Low maintenance, energy efficient and environmentally clean
- Longer running time than any lift in its class keeps you on the job longer, increasing your productivity
- Lightweight design for transport in freight elevators
