Snorkel SR626E – 2.6T Electric RT Telehandler 5.79m Max Lift
The SR626E is the electric version of the SR626 rough terrain telehandler – an industry first. Its full-time 4-wheel drive is powered by lithium-ion batteries for long-lasting durable performance. Built compact, the SR626E is highly maneuverable with reduced noise and zero emissions that is suitable for indoor use.
Key Specs
- Max. Lift Capacity: 2,600kg
- Max. Lift Height: 5.79m
- Max. Forward Reach: 3.1m
- Weight: 4,800kg
- Battery Capacity: 300Ah / 400Ah
See Full Specifications
| Max. lift capacity | 2,600kg |
|---|---|
| Max. lift height | 5.79m |
| Max. forward reach | 3.1m |
| Width | 1.89m |
| Stowed Height | 1.93m |
| Length to fork face | 4.19m |
| Wheelbase | 2.5m |
| Ground Clearance | 220mm |
| Max. drive speed | 12km/h |
| Raise/Lower Time | 6.9 / 5 seconds |
| Hydraulic flow (per minute) | 80L |
| Hydraulic pressure | 230bar |
| Hydraulic oil capacity | 70L |
| Outside Turning Radius | 3.25m |
| Tyres | 12 x 16.5 |
| Power Source | Lithium-ion 80V 32kWh batteries |
| Operating temperature | (-)20 C to (+)45 C |
| Charger | on-board, single phase |
| Weight | 4,800kg |
- Lithium-ion batteries
- Full-time 4-wheel drive
- 4-wheel steer – selectable front, crab & coordinated
- Auxiliary hydraulic circuit on the boom
- Variable speed hydrostatic drive
- Fully enclosed cab with heat
- Proportional joystick
- Illuminated gauge and switch panels
- Color LCD display with machine & engine diagnostics
- Adjustable suspension seat
- Fixed 1200mm carriage & 1200mm floating forks
- 2000 charging cycles/2 year *** lithium battery warranty
- 2 year parts & labour, 5 year structural warranty
