Snorkel SR626 – 2.6T Diesel RT Telehandler 5.79m Max Lift
The Snorkel SR626 compact rough terrain telehandler is a robust performer. Designed for working in confined spaces, the telehandler offers proportional controls for precise maneuvering. Full-time 4-wheel drive and power assisted steering make this compact telehandler well-suited for construction applications.
Key Specs
- Max. Lift Capacity: 2,600kg
- Max. Lift Height: 5.79m
- Max. Forward Reach: 3.2m
- Engine: Yanmar 52kW Stage V diesel
See Full Specifications
| Max. Lift Height | 5.79m |
| Max. Lift Capacity | 2,600kg |
| Max. Forward Reach | 3.2m |
| Overall Width | 1.89m |
| Stowed Height | 1.93m |
| Wheel Base | 2.5m |
| Ground Clearance | 220mm |
| Length to fork face | 4.19m |
| Max. drive speed | 27km/h |
| Raise/Lower Time | 6.9/5 sec |
| Outside Turning Radius | 3.25m |
| Tires | 12 x 16.5 |
| Fuel Capacity | 80L |
| Power Source | Yanmar 52kW Stage V diesel |
| Hydraulic Pressure | 230bar |
| Hydraulic Flow (per min) | 70L |
| Hydraulic Oil Capacity | 70L |
| Weight | 4,700kg |
- Full-time 4-wheel drive
- 4-wheel steer – selectable front, crab & coordinated
- Selectable front, crab & coordinated steering modes
- Auxiliary hydraulic circuit on the boom
- Variable speed hydrostatic drive
- Fender (set of 4)
- Fully enclosed cab with heat
- Proportional joystick
- Illuminated gauge and switch panels
- Colour LCD display with machine & engine diagnostics
- Flashing beacon
- Fixed 1200mm carriage with 1200mm floating forks
- 2 year parts & labour, 5 year structural warranty
