Snorkel S2770BE Bi-Energy Scissor Lift – 10.1m Max Working Height
Key Specs
- Max Working Height: 10.1m | 33.1 ft
- Max Platform Capacity: 580kg | 1278 lb
| Specifications | |
| Max Working Height | 10.1 m |
| Max Platform Height | 8.1 m |
| Platform Length (Extended) | 4.0 m |
| Platform Width | 1.6 m |
| Platform Capacity | 580 kg |
| Weight | 3,186 kg |
| Overall Length | 3.4 m |
| Overall Width | 1.8 m |
| Stowed Height (Rails Up) | 2.61 m |
| Stowed Height (Rails Down) | 1.83 m |
| Ground Clearance | 330 mm |
| Power Source | Bi-Energy |
Standard Features
- DC & diesel power – for indoor & outdoor work
- 4 wheel drive
- Roll-out deck extension
- 4 hydraulic stabilizers with automatic leveling
- Non-marking foam filled tires
- Proportional controls
- Power line to platform
- Platform overload system
- Drive motion alarm
- Descent alarm
- Fold-down guardrails
- Flashing amber light (x2)
- Oscillating axle
- Hour meter & on-board diagnostics display
- Manual lowering valve
- Dual lanyard attachment points
- 2 years parts & labor, 5 year structural warranty
