Snorkel ML10I – 408KG Manual Load Lifter 3.4m Max Lift
The ML10I industrial material lift is built to handle the work. Designed narrow to manoever through standard doorways without tilting back, this material lift is also robust for heavy-duty applications. For improved productivity, it is equipped with a dual handle, shift-on-the-fly, two-speed winch.
Key Specs
- Lift height – forks up: 3.4m
- Lift height – forks down: 2.7m
- Stowed height: 1.9m
- Weight: 106kg
See Full Specifications
| Lift height – forks up | 3.4m |
| Lift height – forks down | 2.7m |
| Stowed width | 0.77m |
| Stabiliser width | 1.63m |
| Stowed length | 0.85m |
| Operating length | 1.57m |
| Stowed Height | 1.9m |
| Fork width (outside) | 0.58m |
| Fork length | 0.76m |
| Ground Clearance | 60mm |
| Max. load capacity (0.36m load centre) | 408kg |
| Max. load capacity (0.61m load centre) | 340kg |
| Max. load capacity (1.07m load centre) | 159kg |
| Min. load height | 150mm |
| Winch (high speed) | 13.1 cranks/m |
| Winch (low speed) | 49.2 cranks/m |
| Weight | 106kg |
- Non-marking transport/loading wheels
- Dual handle, two-speed shift-on-the-fly winch
- Metal cable pulleys with sealed bearings
- Heavy-gauge aluminium extrusions
- Heavy-duty, non-marking casters
- Crane attachment point
- Cable guard
- Mast brake
- 2 year parts & labour, 5 year structural warranty
Additional information
