Skyjack SJ4740 Electric Scissor Lift – 13.86m Max Working Height
Key Specs
- Max Working Height: 13.86 m / 45.4 ft
- Max Platform Capacity: 349 kg | 770 lb
| Specifications | |
| Max Working Height | 13.86 m |
| Max Platform Height | 11.86 m |
| Overall Length | 2.4 m |
| Overall Width | 1.2 m |
| Stowed Height | 2.03 m – 2.53 m |
| Extension length | 0.91 m |
| Platform Capacity | 349 kg |
| Weight | 2934 kg |
| Ground Clearance | 114 mm |
Standard Features
■ Drivable at full height
■ Variable speed, front wheel hydraulic drive
■ Dual holding brakes
■ SKYCODED™ Colour coded and numbered wiring system
■ On-board visual interface with diagnostic capabilities
■ Shroud style, impact resistant composite control box with
extended cable
■ Proportional controls for drive & lift functions
■ Tilt sensor (3.5° x 1.5°)
■ 0.91 m Roll out extension deck
■ 24V DC Power source
■ Low voltage battery protection
■ 25% Gradeability
■ Solid rubber, non-marking tyres
■ Pothole protection system
■ Wiring for AC outlet on platform
■ Tilt alarm with drive & lift cut-out
■ All motion audible alarm
■ Lanyard attachment points
■ Operator horn
■ Forklift pockets and tie down/lift lugs
■ Overload sensing system
■ Fold down hinged railing system
■ Half height spring hinged entry gate
■ Telematics ready
■ White noise alarm
■ Flashing light
