Skyjack SJ3220 Electric Scissor Lift – 7.95m Max Working Height
Electric Scissor Lift
Key Specs
- Max Working Height: 7.95 m / 26 ft
- Max Platform Capacity: 408kg | 900 lb
| Specifications | |
| Max Working Height | 7.95 m |
| Max Platform Height | 5.95 m |
| Overall Length | 2.32 m |
| Overall Width | 0.84 m |
| Stowed Height | 1.75 m – 2.10 m |
| Extension length | 0.91 m |
| Platform Capacity | 408 kg |
| Weight | 1776 kg |
| Ground Clearance | 102 mm |
Standard Features
- Drivable at full height
- Variable speed, rear two wheel hydraulic drive
- Dual holding brakes
- SKYCODED™ Colour coded and numbered wiring system
- On-board visual interface with diagnostic capabilities
- Shroud style, impact resistant composite control box with
- extended cable
- Proportional controls for drive & lift functions
- Tilt sensor (3.5° x 1.5°)
- 0.91 m Roll out extension deck
- 24V DC Power source
- Low voltage battery protection
- 25% Gradeability
- Solid rubber, non-marking tyres
- Pothole protection system
- Wiring for AC outlet at platform
- Tilt alarm with drive & lift cut-out
- All motion audible alarm
- Lanyard attachment points
- Operator horn
- Forklift pockets and tie down/lift lugs
- Overload sensing system
- Fold down hinged railing system
- Half height spring hinged entry gate
- Telematics ready
- White noise alarm
- Flashing light
