Sinoboom TB20J Plus – 22m Max Working Height Boom lift
Engine Powered Telescopic Boom Lift
Key Specs
- Max Working Height: 22 m | 72.1 ft
- Platform Capacity: 300~454 kg | 661~1000 lb
| Specifications of Sinoboom TB20J Plus | |
| Max Working Height | 22 m |
| Max Platform Height | 20 m |
| Max Outreach (horizontal) | 16.1 m |
| Platform Size | 0.91 x 2.44 m |
| Max Platform Capacity | 454 kg |
| Weight | 11,900 kg |
| Power Source | Diesel Cummins, QSF2.8t3NA60, 43 kW |
| Stowed Length | 9.99 m |
| Stowed Width | 2.49 m |
| Stowed Height | 2.79 m |
| Ground Clearance | 0.46 m |
High Capacity
■ Plus series boom lifts hold up to 1,000 lb (restricted)/ 661lb
(unrestricted)platform capacity allowing you to carry up to 3 occupants
plus material and tools to get your job done easily
Oscillating Function
■ Both the active and inactive states have a oscillating function, allowing work
on inclined and uneven ground
Precision Performance
■ The upper control box is equipped with 3 full-proportional handles for gradual
control of boom lifting, telescoping, turntable rotation and driving speed
■ Operate with smooth starting and stopping and precision approach to your
worksite target
