JLG X26J Plus – 25.6m Max Working Height Boom lift
Bi-Energy Compact Crawler Boom Lift
Key Specs
- Max Working Height: 25.6 m | 83.98 ft
- Platform Capacity: 230 kg | 507 lb
| Specifications | |
| Max Working Height | 25.6 m |
| Max Platform Height | 23.6 m |
| Max Outreach (horizontal) | 13.75 m |
| Platform Size | 0.69 x 1.34 m |
| Max Platform Capacity | 230 kg |
| Weight | 4,365 kg |
| Power Source | Diesel Kubota D902 16.1 kw AC electric motor 230V, 50Hz, 2.2kW |
| Stowed Length | 6.35 m |
| Stowed Width | 1.34 m |
| Stowed Height | 1.99 m |
| Ground Clearance | – |
