JLG ERT2669 Electric RT Scissor Lift – 10m Max Working Height

  • Max Platform Height: 10m | 32.8 ft
  • Max Platform Capacity: 680 kg | 1500 lb
Compare Key Specs
Specifications
Max Working Height  10 m
Max Platform Height  8 m
Platform Length (Extended)  4.37 m
Platform Width  1.60 m
Platform Capacity  680 kg
Weight  3,913 kg
Overall Length  3.3 m
Overall Width  1.76 m
Stowed Height (Rails Up)  2.46 m
Stowed Height (Rails Down)  1.3 m
Ground Clearance  257 mm
Power Source  Electric

Standard Features
• 42in Roll-out Deck Extension
• Nickel Plated Pins, Yellow Zinc-Chromate Plated Fasteners
• Pin-Less Fold Down Rail System
• Platform Control Box with LCD Display, USB Charger and Phone Holster
• Self-closing Gate
• Full Time Traction Control
• Lubrication-Free Scissor Arm Bushings
• Manual Descent Pull Cable1
• Oscillating Front Axle
• Scissor Maintenance Prop
• Tie Down Lugs
• 26 x 12 Foam Filled Non-Marking Tires
• AC Receptacle In Platform
• 23 Amp Automatic, SCR Battery Charger
• 8 x 6V, 225 Amp-Hour Batteries (ERT2669,ERT3369)
• 8 x 6V, 310 Amp-Hour Batteries (ERT4069)
• 8 x 6V, 375 Amp-Hour Batteries (ERT4769)
• All Motion Alarm
• Descent Alarm
• Horn
• Hourmeter
• 2WD AC Drive System
• Proportional Lift and Drive
• Lift Sense System
• Tilt Display with Lift Sense System
• Pin-based Load Sensing System
